Building a Modular Shipping Container Interior with CSM Brackets and Strut Channel
In this walkthrough, Channing McCorriston, The Container Guy, demonstrates how to install a modular interior system using CSM brackets and strut channel inside a shipping container.
This method focuses on flexibility, minimal container damage, and long-term adaptability. The result is a clean, organized storage system that can be configured for shelving, pipe storage, tire racks, and more without welding or penetrating the container walls.
Why Use a Strut-Based Interior System?
Traditional container interior builds often involve welding or drilling multiple holes through the container walls. That can damage paint, compromise structural integrity, and increase the risk of leaks.
The CSM bracket and strut channel system eliminates those issues.
Key advantages include:
-
No welding required
-
No bolting through container walls
-
Preservation of factory paint and coating
-
Fully modular and adjustable layout
-
Installation achievable with basic tools
The only penetration typically required through the container is for power entry. Everything else mounts directly to the corrugations using self-threading screws.
Bracket Spacing and Layout Options
Shipping container corrugations are spaced approximately 11 inches center-to-center.
Brackets can be installed:
-
On every corrugation
-
Every second corrugation
-
Every third or fourth corrugation
Spacing depends on your load requirements and budget. Closer spacing increases strength, while wider spacing reduces material cost and installation time.
Strut channels can be mounted flush to the corrugation for non-insulated builds or offset to allow space for spray foam insulation and thermal breaks.
Installation Process Overview
The installation begins by marking the corrugations and pre-drilling holes using a 7/32 inch drill bit.
Bottom brackets are secured to the floor using 3/8 hex head sheet metal screws, which do not require pre-drilling. Top brackets are center-punched, drilled, and fastened with self-tapping screws to ensure proper alignment.
Once brackets are mounted, the strut channel slides into place.
The system uses spring nuts inside the strut channel. These specialized nuts include a spring backing that holds them in position while bolts are tightened. They insert one way and resist spinning, making installation efficient and adjustable.
Modular Storage Accessories
One of the biggest advantages of this system is its flexibility.
Heavy Duty Shelving Brackets
The 18-inch shelving brackets allow adjustable height placement and can support two 2x10 boards, creating a shelf roughly 19 to 20 inches deep.
When shelving is installed on both sides of the container, a center aisle greater than three feet remains, preserving usable walking space.
Bolt holes spaced every four inches allow precise height adjustments.
Pipe Racks
Pipe racks mount using the same spring nut system and are ideal for storing pipe, ladders, chains, extension cords, and straps.
Because of angled mounting profiles, some bolts require tightening with a wrench. Rubber caps can be added to exposed edges to reduce injury risk.
Technical Details
-
Corrugation spacing: approximately 11 inches
-
Drill bit size: 7/32 inch
-
Screws: 3/8 hex head sheet metal screws and self-threading screws
-
Shelf bracket width: 18 inches
-
Tire rack tubing: 1¼ inch EMT conduit
Why This System Works
The CSM bracket and strut channel approach delivers:
-
Strong mounting without structural compromise
-
Modular flexibility
-
Reusable and adjustable connection points
-
Expandability for future upgrades
-
Clean, professional interior layout
Spring nuts create solid anchor points that can be repositioned as storage needs evolve.
Final Thoughts
Transforming a shipping container into a modular storage system does not require welding or permanent structural alterations.
With CSM brackets, strut channels, and adaptable accessories, you can build a flexible interior that grows with your needs while maintaining the integrity of the container.
This system offers a practical, durable, and professional solution for maximizing container storage space.
